| MPN | 133071 |
|---|---|
| Brand | Switch Electronics |
| Mounting Style | Panel Mount |
| Unit Quantity | 1 |
| Termination Style | Solder Lug |
| Type | Wirewound Potentiometer |
| Country of Origin | China |
| Resistance Rating | 1KΩ |
| Packaging | Bulk |
| Tolerance Rating | ±5% |
| Power Rating | 2W |
| EAN | 5063200180335 |
Check the listing for details. 1k Wirewound Precision 3590S Potentiometer Pot 2W 5%. Condition: New, Made in China. Listed at 22.12 USD. 1k Wirewound Precision 3590S Potentiometer Pot 2W 5% 1k Wirewound Precision 3590S Potentiometer Pot 2W 5% £ 6.99 Ask a question Mono wirewound potentiometer with a copper shaft suitable for use with user interfaces where a high precision is required. Resistance: 1k Tolerance: 5% Comes complete with washer and nut Solder lug termination Shaft diameter: 6.3mm Shaft length: 20.6mm Body diameter: 22mm Technical Information Value 1KΩ Shaft Diameter 6.3mm Rated Power (Max Voltage: 315V): +70°C 2W, +125°C 0W Tolerance 5% Temperature Coefficient ±100ppm/°C Total Mechanical Rotation 3600° Operating Temperature -55°C to +125°C About Us Shop related items eBay & Ecommerce Stores By.
