Check the listing for details. 22mm18A2NOHigh current waterproof push button switch High head Ring luminescence. Color: Silver, Condition: New. Listed at 11.30 USD. Item specifics Place of Origin:Zhejiang, China (Mainland) Model Number:22C-switch push button Protection Level:IP67 Max. Current:18A Max. Voltage:250VAC Diameter:22mm Switch Combination:2NO-Normal Open Operation type:Momentary or Latching Emitting Type:High Head Ring LED Lamp color:Red Green Yellow Blue White Orange Purple Pink Lamp voltage:2V/3V/6V/12V/24V/36V/110V/220V/250V Waterproof/Protection:IP67/IK10 Rated Voltage/Current:AC250V/18A Shell Metal:Stainless Steel/Copper plating/Aluminum oxide Product name:22MM double pole latching 250VAC 18A switch push button withProduct Description Model Description Model NO. LB-22 metal push button switch Mounting diameter 22MM Head shape High Head Ring LED Switch Combination 1NO 1NC Operation type Momentary/Latch Illuminating type Annular,power symbol,dot Illuminating color red,green,blue,yellow,orange,white,purple,pink Lamp voltage 2V/3V/6V/12V/24V/36V/110V/220V/250V Shell material Stainless steel,aluminum oxide,copper plating The Others ParametersProjectParameterProjectParameter Contact type Slow moving single contact Operation Schedule Connected:1.8mm,Total:3.5mm Contact Resistance ≤50mΩ Actuating Force about 11N Insulation Resistance ≥1000mΩ Mounting panel thickness ≤4mm. customised the others Dielectric Strength 1000VAC min Nut torque 5~14N.m Ambient Temperature -30℃~+80℃ Outshell/Press Key Stainless Steel/aluminum oxide/copper plate Protection Levels IK10 Diffuser PC Electrical Life Rated:2A250VAC- 120,000 times Rated:5A250VAC-60,000 times Rated:10A250VAC-30,000 times Reated:15A250VAC- 20,000 times Nut Base Seat/ Bottom Seat Nickel brass PA66 Mechanical Life Maintained-200,000 times Self-locking-800,000 times Pins Contact PA66 H65 Silver Plated Waterproof IP65/67 Spring Improved steel wireSwitch Rated Load Project Parameter Reated Insulation Voltage AC250V Fusing Current 18A Rated VoltageDC12VDC24VAC250V Rated Current Nonreactive Load181515 Inductive Load544 Led Lamp ParametersProjectParameter Led type High Brightness LED lamp,cool Luminous color Red,Green,Blue,Yellow,Orange,White,Purple,Pink Rated Voltage AC/DC3~8V,AC/DC9~24V,AC/DC 25~48V,AC110V,AC220V Rated Current ≤20mA Reference Life 40,000hours Packaging Details Unit Type: piece Package Weight: 0.034kg (0.07lb.) Package Size: 11cm x 11cm x 11cm (4.33in x 4.33in x 4.33in)
