Check the listing for details. 5PCS LM75A Temperature Sensor High-speed I2C Interface Development Board Module. Condition: New. Listed at 13.88 USD. 无标题文档 >Description LM75A is a high-speed I2C interface, temperature sensor, in the temperature range -55 ℃ ~ + 125 ℃ The temperature was directly converted to digital signals, and to achieve the accuracy of 0.125 ℃. MCU can be read directly via I2C bus data in its internal registers, and through I2C to four data registers operates to set different operating modes. LM75A has three selectable logic address pins, making it possible to connect eight devices without address conflict on the same bus. Features: I2C bus interface, the device address 7 slave address 1001xxx, can expand outside eight devices on the same bus; Power range: 2.8V ~ 5.5V, temperature range: -55 ℃ ~ + 125 ℃; 11 ADC provides a temperature resolution of 0.125 ℃; Temperature accuracy: ± 2 ℃ (-25 ℃ ~ 100 ℃) ± 3 ℃ (-55 ℃ ~ 125 ℃) Programmable temperature threshold and hysteresis set points; In order to reduce power consumption, the current consumption in shutdown mode is only 1.0μA; On power-up the device can be used as a stand-alone temperature controllers; protection: In JESD22A114 standard, it can be 2000V HBM mode; In JESD22A115 standard, can 200V MM mode; In JESD22-C101 standard, it can be 1000V CDM model; In JEDEC Standard (JESD78) latch-up testing done up to 100mA; Small 8-pin package: SO8, TSSOP8 and ultra-small package XSON8U. Package Include: 5PCS LM75A Temperature Sensor High-speed I2C Interface Development Board Module >Payment We only accept payment through Paypal. Items will go to post within 1-2 business days after payment confirmed. Please leave note in PayPal when making the payment if you have any special request (colors/size). >Shipping USA customers: all items will be shipped to address in buyer’s eBay details via ePacket service of USPS & China Post. We’ll offer tracking number for each package. Tracking info can be traced on USPS system. Customers outside of USA: all items will be shipped to address in buyer’s paypal details via Hong Kong post air mail. Before you bid item, please clear you have noticed below details: 7-25 working days: United States 10-25 working days: Canada, United Kingdom, Australia, Japan, New Zealand 2-5 working weeks: Countries in Western Europe, Southeast Asia, Israel, Korea 3-6 working weeks: Russia, Eastern Europe, Mid-East 4-7 working weeks: Mexico, South America Because of some post and custom reason, we ship item to worldwide but exclude the following countries and area: AFRICA: All countries in Africa; ASIA: Afghanistan, Bangladesh, Bhutan, Brunei, Cambodia, China, India, Iraq, Kazakhstan, Kyrgyzstan, Laos, Maldives, Mongolia, Nepal, Philippines, Singapore, Tajikistan, Turkey, Turkmenistan, Uzbekistan, Vietnam; Central America and Caribbean; South America: Colombia, Ecuador, Peru; EUROPE: Italy, Moldova, Romania. We are unable to take any responsibility for any custom delay or tax. Reason is because transit time is highly depended and provided by Postal Service (except weekends and holidays). >Contact Us Normally, we leave positive feedback for you once payment received. We are also hope that you can do me the same. Your support will keep us moving forward forever. If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact me before you return it. If the shipping delay happened, we’re willing to pay refund or resend new item(s).
