Check the listing for details. 6 Axis Mach3 Controller Board Support USB + Ethernet For CNC Engraving Machine. Condition: New. Listed at 170.14 USD. Description 6 Axis Mach3 Controller Board CNC Motion Controller Support USB + Ethernet For CNC Engraving Machine Features: - It also has dual USB/Ethernet (Ethernet) interfaces. - 100M Ethernet interface, built-in network transformer isolation, supports long-distance wired connection. With wireless router, it can realize the wireless connection between PC (notebook computer) and motion control board. - Support 6-axis linkage, 500KHz output at the same time, connected to servo/stepping. Any one axis can be configured as a pulse spindle. - 2 real-time electronic handwheel (MPG) input ports, which can connect 2 electronic handwheels at the same time. When the MACH3 electronic handwheel is set in Multi-Step mode, it has the same real-time performance as the CNC machining center, and runs smoothly. There is no delay in the control board, and the performance of the mechanical system is fully utilized. - With real-time jog, the control panel has no delay, the motor responds quickly and flexibly, and the experience is zero delay. - 18 general digital input points, corresponding to 1 LED indicator, self-defining configuration function in MACH3. - 8 general-purpose digital output points, configurable as: spindle start/stop/coolant/custom M code VBasic programming control - 1 PWM output point for analog spindle speed control: pulse width speed control / 0-10V inverter speed control. - 2 analog inputs, used to adjust the processing speed / jog speed / spindle speed. - 1 status indicator, which can prompt USB/Ethernet (Ethernet) connection, and various statuses of the motor are clear at a glance. - It adopts 6 dual-channel 10Mhz high-speed optocouplers and 28 general optocouplers, totaling 34 optocouplers to isolate all inputs/outputs. Onboard an isolated power supply, high-cost design provides complete anti-interference performance and complete safety protection. - 168M speed, without PC intervention, the signal is processed independently by the motion control card, to ensure that you have real-time and reliability. - Support all versions of Mach3. Support for all versions of Windows XP to Windows10 (32-bit/64-bit), and no driver is required, all versions for Windows are plug and play. - The chip firmware supports upgrades, and users can continuously get the latest function support. - Provide a complete installation manual with clear documentation, illustrations and detailed descriptions. Environmentally friendly copper pluggable terminals 100M Ethernet interface / USB interface / isolated power supply Network cable connection USB cable connection 6-axis output signal (direction signal + pulse signal): 10MHz high-speed optocoupler isolation x12 channels Optocoupler isolation PWM spindle speed control signal output x1 / Optocoupler isolation general output x8 Power input: self-recovery fuse + anti-reverse diode + TVS anti-surge diode Optocoupler isolated NPN input x16 External magnification knob Connect Controller Board To Laptop PC: Connection Via USB Cable Direction Connection Via Ethernet Cable Network cable passes through a router Wireless network (WLAN) Download Manual (EDG381) 1.0.7 version (ZIP/9M). http://leafboy77.com/files/usb_eth_edg381/Mach3_USB_Ethernet_Motion_Board(EDG381)Installation_Manual(english).zip Download Plugin (eMotionMach3.ZIP/0.3M) 1.2.1.0 version. http://leafboy77.com/files/usb_eth_edg381/eMotionMach3.zip Download Latest Mach3: http://www.machsupport.com/software/mach3/ Schematic Diagram: USB main control chip + external magnification knob x2 10MHz high-speed optocoupler isolation x12 channels Optocoupler isolated NPN input x16 + Optocoupler isolated PNP input x2 Optocoupler isolation general output x8 + Optocoupler isolation PWM spindle speed control signal output x1 Ethernet interface chip Power + isolated power Package Included: - 1 x Set of CNC Controller Board Note: - Other items are not included, for demonstration purposes only. Thank you for your understanding! Payment Terms 1. We accept PayPal,Payoneer,Visa Card,Google pay,Credit card etc. 2. We ship to your eBay or Paypal address. Please make sure your eBay and Paypal address is correct before you pay. Shipping Terms 1. We will process the order within the handling time ,if you have any questions, please contact us via eBay message or email. 2. For remote regions of DHL/FedEx..., extra shipping costs might be charged. Usually it costs about 30USD-50USD. We will contact you if shipping company informed us your address belongs to remote area. Thanks for your understanding. Return Terms If you receive the item that not satisfied or defective, please do not open case and kindly notify us within 30 days. We will guide you the returning process for replacement or refund. Custom Duties & Taxes 1. It is buyers responsibility to cover the import duties, taxes.We do not charge any taxes and fees, and the possible taxes and fees will be collected by the platform or by third parties such as customs and carriers. 2. Please check with your countrys customs office and inform us what/how much should declare before shipping. Feedback 1. Please kindly leave us a positive feedback and 5 star DSR if you satisfied with our product and service. Please feel free to contact us firstly if you have any problem with your order, we are responsible and credible seller and will solve the issue it for you asap. 2. If you are dissatisfied for any reason, please dont be quick to leave us neutral or negative feedback. We work hard to make sure EVERY CUSTOMER 100% SATISFIED and resolve any problem for you and always leave positive feedback to all our customers. On Mar 13, 2023 at 02:00:40 PDT, seller added the following information:
