Check the listing for details. 6 Channel Stepper Motor Controller Board for M1S. Condition: New. Listed at 31.95 USD. 6 Channel Stepper Motor Controller Board for M1S The Stepmotor Controller board is designed to control up to 6 step motors and support CAN-FD bus, its layout and pinout are especially organised for 3D printer. FEATURES On board DC step down power supply to provide 5V to ODROID-M1S 6x step motor driver module support 1x CAN-FD bus support 1x ADC channel 2x GPIO inputs 1x MOSFET output Specifications Form Factor Board dimension : 90 (L) x 65 (W) x 16 (H) mm Power input 1x terminal block (7.62mm pitch) * ODROID-M1S will be powered via this terminal. I/O 6x Step motor connector * Step motor driver module is required. 1x CAN bus 1x ADC input 1x MOSTFET output 2x GPIO input (internal pull up) NOTES https://wiki.odroid.com/accessory/add-on_boards/stepperboard 6 Channel Stepper Motor Controller Board for M1S The Stepmotor Controller board is designed to control up to 6 step motors and support CAN-FD bus, its layout and pinout are especially organised for 3D printer. FEATURES On board DC step down power supply to provide 5V to ODROID-M1S 6x step motor driver module support 1x CAN-FD bus support 1x ADC channel 2x GPIO inputs 1x MOSFET output Specifications Form Factor Board dimension : 90 (L) x 65 (W) x 16 (H) mm Power input 1x terminal block (7.62mm pitch) * ODROID-M1S will be powered via this terminal. I/O 6x Step motor connector * Step motor driver module is required. 1x CAN bus 1x ADC input 1x MOSTFET output 2x GPIO input (internal pull up) NOTES https://wiki.odroid.com/accessory/add-on_boards/stepperboard &times Buy now and save! Shipping info Click the Shipping & Payments tab above the listing description for more info Price: $7.95 (local shipping) See more... USPS Ground Advantage - $7.95 Economy International Shipping - $30.95 USPS Priority Mail International - $28.00 FedEx International Economy - $50.00 Click the Shipping & Payments tab above the listing description for more info! Additional delivery notes PICK UP OPTION Sorry, our items are NOT available for pick-up. PAYMENT Immediate payment is required upon selecting "Buy It Now" or upon checking out through the cart. We accept payment via U.S. PayPal accounts and all Major Credit Cards, Debit Cards & Google Pay. We are legally required to collect sales tax in those states and localities where we maintain a physical presence (nexus). The applicable amount of sales tax charged to an order will be calculated based on the shipment destination's state and local sales tax laws. Thank you for shopping with us on eBay! Additional Information No additional information at this time Ask seller a question You might also like C1 3.2 inch Touchscreen Display Shield HDMI 2.0 4K-Capable Cable (Standard A to A) MicroUSB-DC Power Bridge Board JustBoom DAC Universal Contact To contact our Customer Service Team, simply click the button here and our Customer Service team will be happy to assist. Ask seller a question © ameriDroid Shipping & Payments Shipping is a flat rate across US at a rate of $7.95 Payment Accepted Payment Methods Immediate payment is required upon selecting "Buy It Now" or upon checking out through the cart. We accept payment via U.S. PayPal accounts and all Major Credit Cards, Debit Cards & Google Pay. We are legally required to collect sales tax in those states and localities where we maintain a physical presence (nexus). The applicable amount of sales tax charged to an order will be calculated based on the shipment destination's state and local sales tax laws. Thank you for shopping with us on eBay! Returns Returns are accepted Items must be returned within 30 days of the auction ending Buyer will pay for return shipping. eBay integration by
