Check the listing for details. Accu-Cable AC3PDMX15 15' 3-Pin DMX Cable. Condition: New. Listed at 13.99 USD. Accu-Cable's AC3PDMX15 is a 15 ft 3-pin DMX cable with XLR connectors. 22 AWG stranded (0.15 x 19 ) tinned copper conductors, polyethylene insulation, twisted pair, polyethylene inner jacket, Duofoil® (100% coverage) and cotton plus a tinned copper braid shield (85% coverage), PVC jacket.Specifications:Conductor:Number of Pairs: 1Total Number of Conductors: 2AWG: 22Stranding: 0.15 x 19Conductor Diameter: .0354"Conduct or Material: TC-Tinned CopperInsulation: Insulation Material PE PolyethyleneLay Length:Lay Length: 2.5"Direction: Left Hand LayTwists: 4.8 per footInner Jacket:Inner Jacket Material: PE- PolyethyleneInner Jacket Diameter: 0.055"Pair Color Code: Black/WhiteOuter Shield:Outer Shield Trade Name: Duofoil®Outer Shield Type: Tape/BraidOuter Shield Material:Layer Number:1, Material Trade Name: Dufoil®, Type: Tape, Material: Aluminum Foil-Polyester, Coverage %: 100Layer Number: 2, Material Trade Name: Dufoil®, Type: Braid, Material:TC-Tinned Copper, Coverage %: 85Outer Jacket: Outer Jacket Material: PVC-Polyvinyl ChlorideOverall Nominal Diameter: Overall Nominal Diameter: .229"Mechanical Characteristics:Operating Temperature Range: (-30 degrees C To + 75 degrees C)Bulk Cable Weight: 31 lbs/1000Minimum Bend Radius (Install): 3.2"Maximum Recommended Pull Tension: 72 lbs.Electrical Characteristics:Nominal Characteristic Impedence: 110 OhmsNominal Capacitance Conductor to Conductor @ 1KHz: 12.8 pF/f tNominal Cap Cond. To Other Cond. & Shield @ 1KH z: 23 pF/ftNominal Velocity of Propagation: 66%Nominal Delay: 1.6 Nanoseconds per footNominal Conductor DC Resistance @ 20 degrees C: 24 Ohms/1000 ftNominal Outer Shield D C Resistance @ 20 degrees C: 3.4 Ohms/ 1000 ftNominal Attenuation (dB/100 ft): 0.6 (@ 1 MH z) dB/100 ftMaximum Recommended Current: 2.1 A mps per conductor @ 25 degree C
