| Brand | Blackmagic Design |
|---|---|
| MPN | BDLKULSTMP010G |
| Model | Blackmagic Design BDLKULSTMP010G |
| Type | Video Capture |
| System Connection | USB-C (Thunderbolt 3) |
| Video I/O | Input 1x BNC (12G-SDI) Female Output 4x BNC (12G-SDI) Female 1x B |
| Audio I/O | Output 2x XLR 3-Pin Analog Female 1x 1/4 TRS Analog Female |
| Other I/O | Input/Output 1x Thunderbolt 3 3.0 / 3.1/3.2 Gen 1 1x USB-C 3.0 / |
| Video Resolution | BNC Input/Output (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV) 4096 x 2160 up to 23.98/24/25/29.97/30/50/59.94/ |
| Audio Format | Analog Output: 48 kHz / 24-Bit |
| Embedded Audio | HDMI/LAN (RJ45)/SDI/USB |
| HDCP Support | No |
| HDR Support | Yes: Hybrid Log Gamma |
| OS Compatibility | Windows 10 to 11 macOS 13 or Later Linux |
| Power I/O | 1x IEC C14 (100 to 240 VAC ) Input |
| Operating Conditions | 41 to 104°F / 5 to 40°C up to90% Humidity |
| Storage Conditions | -4 to 113°F / -20 to 45°C up to90% Humidity |
| UPC | 9338716008999 |
Check the listing for details. Blackmagic Design Media Player 10G. Condition: New. Listed at 1045.00 USD. The two SDI outputs are then connected to a live production switcher where they can be keyed over video. Place it on the desktop, or it can be rack-mounted using a Blackmagic Universal Rack Shelf. There's also a headphone socket, a speaker, and a speaker enable button.
