Check the listing for details. CINCINNATI M-Type Miller 1M, 2M Horizontal Milling Machines Operator Manual 0123. Condition: New. Listed at 45.00 USD. Manual Description: Number of Pages: 31 This is a reproduction of an original Cincinnati M-Type Millers Operator's Instructions Manual. This manual covers both the 1M and 2M horizontal milling machines. This manual covers the proper operating procedures, adjustments, and maintenance. It contains cross-sectional diagrams of the spindle and the dividing head. It also covers the set up and operational instructions for the dividing head. See contents below. Contents: MACHINE SPECIFICATIONS...........................................3 LUBRICATION General Instructions.............................................4 Chart............................................................5 Specifications...................................................6 OPERATING INSTRUCTIONS Starting the Machine.............................................6 Changing Spindle Speeds..........................................7 Changing Feeds...................................................7 Feeds............................................................7 Power Table Feed.................................................7 Power Cross Feed.................................................7 Power Vertical Feed..............................................8 Power Quick Traverse.............................................8 SETTING UP THE MACHINE Setting Up the Fixture and Cutters...............................9 Overarm, Supports, and Braces....................................9 Clamping Devices for Sliding Units..............................11 Trip Dogs.......................................................11 Reversing the Direction of Rotation of the Spindle..............11 Changing from Cast Iron to Steel................................11 ADJUSTMENTS Adjusting the Gibs..............................................12 Increasing the Driving Power of the Clutch......................12 Adjusting the Lead Screw Bearings...............................12 Adjusting the Spindle Bearings..................................13 Adjusting the Cross Screw Bearings..............................13 Adjusting the Driving Chain.....................................14 DIVIDING HEAD Setting Up the Dividing Head and Change Gears...................15 How to Set the Index Plate......................................15 How to Calculate Indexing.......................................16 Indexing with the Front Plate...................................17 Indexing 2 to 400,000 with new wide Range Divider...............18 Clamping the Spindle in Place...................................19 Adjusting the Worm..............................................19 TABLES Standard Index Tables...........................................20 High Number Index Tables........................................21 Leads, Angles, and Change Gears for Spiral End Mills............23 Leads, Angles, and Change Gears for Spiral Milling Cutters......23 Change Gears, Angles, and Leads for Cutting Spirals.............24 Table of Leads..................................................26 CALCULATING MACHINING TIME......................................30 Overview I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page,and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.Visit our eBay Store!We have over 1,100 manuals available. From our shop to yours. We get this. But you get this! Why settle for anything less?We can't make pictures a lot better than the original, but we can fix everything else. Shipping: We ship every M-T-W-T-F except US holidays. All of our manuals are shipped with Delivery Confirmation. We stamp “Do Not Bend” on them to ensure that your manual arrives quickly in good condition. Any package that weighs more than 15.9 oz cannot be shipped First Class, and will be shipped Media Mail. Priority and Express mail options are available to purchase. Since we offer free shipping, we cannot reship manuals for free, due to inaccurate or insufficient addresses. Reshipping Fees for inaccurate or insufficient addresses: $5.00 for the first manual and $2.50 for each additional manual. Service: We have been providing this service to fellow craftsman and machinist for over 20 years. We treat everyone as we would like to be treated. We try to take care of all our customers. We do more than sell manuals, we have a complete woodworking and machine shop. We operate all kinds of machinery everyday.
