| Brand | Danfoss |
|---|---|
| Voltage | 115 V |
| Power Phase | 1 Phase |
Check the listing for details. Danfoss Comp GPY14NDa 1/3 HP LBP/MBP R134 115V. Condition: New. Listed at 189.00 USD. Technical Data Sheet Compressor model GPY14NDa Voltage 115V 60Hz ~1 Refrigerant R134a APPLICATION COMPRESSOR MOTOR Application Low-Medium Back Pressure Displacement 14,32 cm³ Nominal Power 1/3 hp Refrigerant R134a Diameter 29,37 mm Voltage/Frequency 115V 60Hz Evaporating Temp.-35,0 ºC to 0,0 ºC Stroke 21,13 mm Voltage range 103-127 V Expansion Capillar/Valve Net Weight 12,04 Kg Type CSIR Comp. Cooling Fan cooled Oil type ISO VG 32 ESTER Phase number 1 PH Max. ambient temp. 43,0 ºC Oil charge 400 cm³ Locked Rotor Amps (LRA) 39,00 A Compatible refriger. R1234yf Max. Cont. Current (MCC) 8,00 A Main W. resist. at 25ºC 1,02 Ω Start W. resist. at 25ºC 7,89 Ω
