Check the listing for details. 18 Sound 12MB700 Very High Output Mid-Bass Ferrite Transducer 450 W 8 ohm 1 pc. Condition: New. Listed at 269.00 USD. 18 Sound 12MB700 Very High Output Mid-Bass Ferrite Transducer 450W The 12MB700 is a very high sensitivity (101.5 dB 1W/1m) midbass driver with high power handling capabilities. The 12MB700 can be used as either a bass/mid driver in compact 2-way reflex enclosures or as a direct radiating or horn loaded, dedicated midrange driver, in multi-way touring and fixed installation concert and arena systems. Its curvilinear paper cone made from a special high strength wood pulp, has been designed to achieve the best possible linearity within its intended frequency range and to control bell-mode resonances around the cone circumference. The cone is carried by a multi-roll suspension formed of a linen-like material, which is more resistant to aging and fatigue than traditional materials. The 75 mm diameter state-of-the-art voice coil is similar to those fitted to our top-of-the-range 18" and 15" models but it is wound with aluminum wire. It employs our Interleaved Sandwich Voice coil (ISV) technology in which a high strength fiberglass former carries windings on both the outer and inner surfaces to achieve a mass balanced coil. This results in an extremely linear motor assembly with a reduced tendency for eccentric behavior when driven hard. The excellent performance capabilities of this loudspeaker are further enhanced by the Double Demodulating Rings (DDR) designed to dramatically reduce the intermodulation and harmonic distortion and improve transient response. The magnetic structure has been optimized using FEA CAD resource, maximizing the flux density in the voice coil gap. Voice coil cooling has been achieved by incorporating airways between the chassis back plate and the top plate of the magnet, allowing heated air from the voice coil and gap to be channeled away and dissipated by the chassis basket. Due to the increasing use of high power audio systems at outdoor events or in marine environments, the ability to perform properly under inclement weather conditions is a key feature in Eighteen Sound philosophy. Hence, an exclusive treatment has been applied to the cone giving it water repellent properties. In addition, another special treatment has been applied to the top and back plates making the transducer far more resistant to the corrosive effects of salts and oxidization. Product Specifications Nominal Diameter 300 mm (12 in)Rated Impedance 8 OhmAES Power 450 WProgram Power 600 WPeak Power 1200 WSensitivity 101,5 dBFrequency Range 60 - 5000 HzPower Compression -10dB 0,4 dBPower Compression -3dB 1,5 dBPower Compression Full Power 2,8 dBMax Recommended Frequency 4000 HzRecommended Enclosure Volume 10 - 80 lt. (0,3 - 2,83 cu-ft.)Minimum Impedance 5,7 Ohm at 25°CMax Peak To Peak Excursion 22 mm (0,87 in)Voice Coil Diameter 75 mm (3 in)Voice Coil winding material aluminumSuspension M-roll, PolycottonCone Curvilinear, Paper Thiele Small Parameters Fs 49 HzRe 5 OhmSd 0,0531 sq.mt. (82,31 sq.in.)Qms 4,7Qes 0,2Qts 0,19Vas 101 lt. (3,57 cuft)Mms 41 gr. (0,09 lb)101 lt. (3,57 cu-ft.)BL 17,8 TmLinear Mathematical Xmax ± 4,5 mm (± 0,18 in)Le (1kHz) 0,9 mHRef. Efficiency 1W-1m (half space) 99,6 dB Mounting Information Overall diameter 315 mm (12,4 in)N. of mounting holes and bolt 8Mounting holes diameter 7,15 mm (0,28 in)Bolt circle diameter 296 - 300 mm (11,65 - 11,8 in)Front mount baffle cutout ø 282 mm (11,1 in)Rear mount baffle cutout ø 282 mm (11,1 in)Total depth 147,5 mm (5,82 in)Flange and gasket thickness 16,5 mm (0,65 in) Net weight 8 kg (17,66 lb)Shipping weight 9 kg (19,84 lb)Packaging Dimensions 13 x 13 x 7.24"
