| Model | 60 AMP |
| Modified Item | No |
| Custom Bundle | No |
| Compatible Fuel Type | Electric |
| Theme | ESC |
| Type | Electronic (ESC) |
| Bundle Listing | No |
| Part | Electronic Speed Control |
| For Vehicle Type | Airplane |
| Fuel Source | Electric |
| MPN | EFLA1060B |
| For Vehicle Brand | Any |
| Scale | Any |
| Year | 2020 |
| Quantity | 1 |
| Vehicle Type | Airplane |
| Motor Type | Brushless |
| Non-Domestic Product | No |
| Compatible Vehicle Type | Airplanes |
| Compatible Scale | 1:4 |
| Age Level | 8-11 Years |
| Brand | E-Flite |
| Compatible Motor Type | Brushless |
Check the listing for details. EFLA1060B E-Flite Eflite 60 Amp Pro V2 Brushless ESC Electronic Speed Control. Condition: New. Listed at 97.99 USD. This is the E-flite "V2" 60-Amp Pro Switch-Mode BEC Brushless ESC. This is a high-quality sensorless brushless electronic speed control with an integrated switch-mode BEC that is very lightweight and efficient. It can operate without the need for a separate receiver battery to power your servos and receivers, saving you weight and complication. This ESC is included in a variety of E-flite airplanes, including the Carbon-Z Splendor, Carbon-Z Cub and Carbon-Z Yak, but is an excellent choice for electric airplanes that can benefit from a 60 amp ESC with a high voltage switch mode BEC. Features: Up to 60 amps continuous current with proper air flow and 75 amps burst current (15 seconds)5A continuous current, 5V switch-mode BEC circuit (proper cooling and airflow required)Stronger BEC for support of most 3-axis stabilization systemsDrive up to 7 analog or 6 digital standard-sized servos with the BEC on any recommended input voltage3- to 6-cell Li-Po, 9- to 18-cell Ni-MH/Ni-Cd input voltageFinned heat sinksProgrammable motor brakingSafe power-arm mode prevents accidental startsProgrammable low voltage cutoff with settings for 3-cell Li-Po (9V), 4-cell Li-Po (12V), 5-cell Li-Po (15V), 6-cell Li-Po (18V) or 74% of battery starting voltageProgrammable throttle input range (1.1ms - 1.9ms or 1.2ms - 1.8ms)Programmable soft start for helis and airplanesAuto motor shut down if signal is lost or there is interferenceProgrammable timing-5 user-selectable ranges for use with a large variety of brushless motorsUtilizes new smaller MOSFET technology to minimize weightRadio system power on/off switchPre-wired connectors-E-flite EC3 connector on battery input and 3.5mm gold bullet connectors on motor output leads Specifications: Continuous Maximum Current: 60A Input Connector Types: 13 AWG with E-flite EC3 connector Output Connector Types: 13 AWG with 3.5mm gold bullet connectors Momentary Peak Current: 15 sec @ 75A with proper cooling air flow Length: 2.85 in (73.0mm) Width: 1.30 in (33.0mm) Height: 0.61 in (15.5mm) Weight: 2.65 oz (75.0 g) Cells w/BEC: 3-6S Li-Po or 9-18 Ni-MH/Ni-Cd
