| Brand | Epic |
|---|---|
| Type | Connection Socket |
| Maximum Amperage | 35 A |
| Voltage | 6 KV |
| Model | H-BS 6 BS 35A 400V 6kV 3 Connector Insert |
| Number of Outlets | 6 |
| MPN | 10171000 |
| Application | Automotive, Branch Circuit, Commercial, Control Equipment Panels, Data Centers, Electrical Wiring, Instruments, Marine, Telecommunications, Transportation, Travel |
| Country of Origin | Germany |
Check the listing for details. Epic 10171000 H-BS 6 BS 35A 400V 6kV 3 Connector Insert. Condition: New, Made in Germany. Listed at 20.00 USD. EPIC® H-BS 6 ETIM 5.0 Class-Description: Contact insert for industrial connectors Classification ETIM 6: ETIM 6.0 Class-ID: EC000438 ETIM 6.0 Class-Description: Contact insert for industrial connectors Rated voltage (V): IEC: 500 VUL: 600 VCSA: 600 V Conductor - conductor: 690 V Rated impulse voltage: 6 kV Rated current (A): IEC: 35 A UL: 35 A CSA: 35 A Pollution degree: 3 Contact resistance: < 2 mOhm Contacts: Copper alloy, hard silver-plated Number of contacts: 6 + PE Termination methods: Screw termination: 0.5 - 6 mm² Stripping length (mm): 8 Cycle of mechanical operation: 100 VDE-tested: Certified production control: VDE-REG. no.: B437 UL-tested: UL File Number: E75770 and E483837 Temperature range: -40°C to +100°C, short-term up to +125°C
