Check the listing for details. ETC UFMP8 8 Zone Mini Relay Panel. Condition: New. Listed at 824.00 USD. The UFMP8 from ETC is a 8-zone DMX Foundry Mini Panel with eight relays and eight 0-10V dimming outputs. Each Foundry Mini Panel from ETC can be wired with a discrete power input for each circuit, or a single input may be shared across multiple circuits. With support for both 120V and 277V circuits simultaneously, as well as normal and emergency circuits, allowing these Foundry Mini Panels to offer unmatched flexibility. Fully isolated 0-10V dimming is also standard for each output, meaning Foundry Mini Panels offer outstanding versatility in a compact, robust package. DMX-controlled Unison Foundry™ products are the perfect partners for Unison Paradigm® and Mosaic® systems to create a complete, economical lighting control package. The Foundry Mini Panel takes 20A branch circuit input and provides four or eight switched power control outputs with fully-isolated 0-10V dimming per output.Applications:Arena and stadium suitesOffice buildingsConference and meeting roomsHealthcare facilitiesHouses of worshipClassroomsHospitality and restaurantsRetailETC UFMP Foundry Mini Panel Features:Switched power control of four or eight circuits with 0-10V dimming120 or 277VAC power input per zone20 Amp fully rated relays for use with general purpose, tungsten, fluorescent, LED and plug loads0-10V dimming output per zone for direct connection to dimming ballasts and LED driversDemand Response load shedding contact inputUL924 control bypass via:Contact closure inputNormal power loss sense feed terminalsDMX controlled and RDM configurableETC UFMP Foundry Mini Panel Series Specifications:Functional:Control for up to eight zones of switching for lighting and plug loadsControl for up to eight zones of 0-10V dimming for LED drivers and fluorescent ballastsUL924 emergency-lighting control via contact closure and power loss sense feed terminalDemand Response input provided by a power company can enforce a maximum level per circuit while activeSupports USITT DMX512-A (ANSI E1.11)Supports RDM (ANSI E1.20)Mechanical:Constructed of 16-gauge cold-rolled steel, finished in fine-textured, black powder coatWall-mount installation; -- rated for installation in plenum air spaceClass-1 voltage barrier prevents access to line-voltage wiring with front panel removedOptional voltage divider allows for separation of normal and emergency circuits in a single controller where allowed by local codesElectrical:100-277V, 50/60Hz power input per circuit with support for pass thou to multiple circuitsSupports 120V and 277V circuits within the same panel20-Amp, fully-rated bi-state latching relay per output0-10VDC control rated for up to 100mA sink per output0-10V outputs are fully isolated from ground to 2500V RMSRising clamp screw terminal wiring connections for:Line-voltage relay power input, output and pass-through with support for 14-8 AWG wireLow-voltage 0-10V dimming output per zone with support for 22-16 AWG wireSeparate normal power sense feed input for UL924 emergency lighting bypassUL924 emergency lighting control contact closure input with support for 22-16 AWG wireDemand Response contact input with support for 22-16 AWG wireDemand Response input supports Normally Open (NO) operationUL924 contact closure input supports normally open (NO) or normally closed (NC) operationOnboard status indicators for controller power, DMX signal, Demand Response input, and UL924 emergency lighting controlSlide switch configuration for:UL924 operation (NO/NC)UL924 inclusion per circuit (on/off)UL and cUL LISTED -- Conforms to UL508, UL2043, UL916 and UL924DMX Input Port:Optically-isolated input from the Mini Panel electronicsWithstands fault voltages of up to 250VACIntegrated DMX/RDM terminationConfiguration:Remote configuration available via RDM devices such as:ETC control console with RDM functionalityETC DMX/RDM gateway networked to a device running ETC Net3 Concert softwareManual configuration of the starting DMX address, UL924 bypass, and Demand Response on the controllerThermal:Ambient room temperature: 32 to 122°F (0 to 50°C)Ambient humidity: 5 to 95% non-condensingPhysical:Dimensions (HxWxD): 14" x 12" x 3"Weight: 9 lbsNOTE: Optional voltage divider available for use of mixed normal and emergency circuits in a single controller; where allowed by local code.
