Check the listing for details. Evertz 2410MD-HSN down converter with Power Supply. Condition: Used. Listed at 189.99 USD. Evertz 2410MD-HSN down converter with Power Supply The 2410MD-HSN Monitoring Downconverter provides an inexpensive method of confidence monitoring your 1.5Gb/s HD signals on standard definition monitors. This High Definition Downconverter is ideal to use with your existing standard resolution monitors whether they have Composite Analog or Serial Digital inputs. The 2410MD-HSN accepts 1080i /1080psF and 720p and provides a fixed output frame rate (selectable to 50 or 60Hz) regardless of the input 720/1080 rate. Pedestal is selectable on/off when output is NTSC. In segmented frame mode, the 2410MD-HSN down converts the 1080p/24sF input video to 525i/60 with a 3:2 pulldown or 625i/50 with a 24:25 pulldown. The 2410MD-HSN repeats fields to create the 3:2 or 24:25 pulldown of the picture content with a random pulldown cadence on the downconverted output. Indicator LED • Signal presence • Module Status Down-conversion Format • Letter Box • Side Crop • 4x3 Squeeze • On-screen markers show 4:3 aspect ratio and safe area Input • Serial digital 1.5Gb/s HD • SMPTE 292M Standards: 1080i/60, 1080i/59.94, 1080i/50, 720p60 & 720p/59.94, 1080p/24sF, 1080i/23.98sF & 1080p/25sF Output • 2 HD 1.5Gb/s reclocked outputs • 2 NTSC down converted outputs • 1 SD down converted output Serial Video Input: Standard: SMPTE 292M, 1080i/60, 1080i/59.94, 1080i/50, 1080p/24sF, 1080p/23.98sF, 1080/25sF, 720p60 & 720p/59.94, Connector: 1 BNC per IEC 61169-8 Annex A Impedance: 75Ω Equalization: Automatic 75m @ 1.5Gb/s with Belden 1694A (or equivalent) HD Reclocked Video Output: Standard: Same as input Connectors: 2 BNC per IEC 61169-8 Annex A Signal Level: 800mV nominal DC Offset: 0V ±0.5V Rise and Fall Time: 200ps nominal Overshoot: < 10% of amplitude Wide Band Jitter: < 0.2 UI SD Serial Digital Video Output: Standard: Serial component 270Mb/s (SMPTE 259M-C) 525i/59.94 or 625i/50 Dip Switch selectable Connectors: 1 BNC per IEC 61169-8 Annex A Signal Level: 800mV nominal DC Offset: 0V ±0.5V Rise and Fall Time: 740ps nominal Overshoot: < 10% of amplitude Return Loss: > 15dB Wide Band Jitter: < 0.2 UI Analog Video Output: Standard: Analog composite NTSC or Analog composite PAL Dip Switch selectable Connectors: 2 BNC per IEC 61169-8 Annex A Signal Level: 1V p-p nominal, internally adjustable DC Offset: 0V ±0.1V Return Loss: > 45dB up to 6MHz Impedance: 75Ω Electrical kd102 m bag
