Check the listing for details. Extron P/2 DA2xi Two Output VGA Distribution 60-506-03 w/Power Supply. Condition: Used. Listed at 24.99 USD. The Extron P/2 DA2xi and P/2 DA2xi MT are one input, two output, VGA distribution amplifiers. Both models come in smaller-sized and durable metal enclosures that can be easily installed in small, tight places. They're small and portable enough to fit into a briefcase for presenters on-the-go. Each model offers 350 MHz (-3dB) of RGB video bandwidth, and are compatible with VGA-QXGA graphic cards, projectors and flat panel displays. Adjustable gain and peaking are DIP switch-selectable.The P/2 DA2xi MT also includes stereo audio, and features a 3.5 mm female jack for audio input and a captive screw connector for balanced or unbalanced stereo output. The P/2 DA2xi includes a detachable, high performance, Extron six foot male to male VGA cable, while the P/2 DA2xi MT includes a detachable six foot male to male VGA with audio cable.Because the P/2 DA2xi and P/2 DA2xi MT are housed in quarter rack width metal enclosures, there are a number of versatile mounting options available to suit virtually any application or environment. With an optional Rack Shelf Kit, either model can be rack-mounted alone or with three other quarter rack width AV products.There are also optional mounting kits available so the P/2 DA2xi and P/2 DA2xi MT can be mounted under a desk or next to a projector.FeaturesInput: One female 15-pin HD connectorOutputs: Two female 15-pin HD connectors350 MHz (-3 dB) RGB bandwidth, fully loadedCompatible with VGA-QXGA resolutionsGain and peaking controlsDIP-switch selectable input and output sync impedancePower and source signal indicatorIncludes detachable 6' (2 m) male-to-male VGA input cableID bits routed to local monitor outputRack-mountable or portableExternal power supply includedVideo Gain P/2 DA2xi Output: 0 dB or 0.4 dB, selectableLocal monitor output: unity P/2 DA2xi MT Output: 0 dB or 0.6 dB, selectableLocal monitor output: unity Peaking P/2 DA2xi Output: selectable, 0.7 dB or 1.4 dB at 100 MHzLocal monitor output: fixed P/2 DA2xi MT Output: selectable, 0 dB or 0.6 dB at 100 MHzLocal monitor output: fixed Bandwidth 350 MHz (-3 dB)Video input Number/signal type 1 VGA-QXGA RGBHV, RGBS, RGsB, RsGsBs, HDTV component video (with adapter), S-video, composite video Connectors 1 female 15-pin HD Pin connections ID bits on pins 4, 11, 12, and 15 are passed through to local monitor output (loop-through).Pin 9 is floating. Nominal level 1.0 Vp-p for Y of component video0.7 Vp-p for RGB and for R-Y and B-Y of component video Minimum/maximum levels Analog, 0.3 V to 1.5 Vp-p with no offset at unity gain Impedance 75 ohms Horizontal frequency 15 kHz to 135 kHz Vertical frequency 30 Hz to 170 Hz Return loss 67 dB @ 20 Hz to 20 kHzAudio input — P/2 DA2xi MT only Number/signal type 1 stereo, unbalanced Connector (1) 3.5 mm stereo jack, female; tip (L), ring (R), sleeve (GND) Impedance 50 ohms unbalanced, 100 ohms balanced Gain error ±0.1 dB channel to channel Nominal level -2 dBu (632 mV) balanced output-10 dBV (316 mV) unbalanced output Maximum level >+10 dBV (3.16 V) (unbalanced) at 1%THD+N NOTE 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBuAudio output — P/2 DA2xi MT only Number/signal type 1 stereo, balanced/unbalanced Connectors (1) 3.5 mm captive screw connector, 5 pole Impedance 50 ohms unbalanced, 100 ohms balanced Gain error ±0.1 dB channel to channel Nominal level -2 dBu (632 mV) balanced output-10 dBV (316 mV) unbalanced output Maximum level (Hi-Z) >+15 dBu (4.36 V), balanced at 1% THD+N, with external power supply Maximum level (600 ohm) >+9 dBm (2.18 V), balanced at 1% THD+N, with external power supplyGeneral External power supply 100 VAC to 240 VAC, 50-60 Hz, 6 watts, external; to 12 VDC, 0.5 A, regulated Power input requirements 12 VDC, 0.2 A Temperature/humidity Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensingOperating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing Cooling Convection, no vents Mounting Rack mount Yes, with optional 1U rack shelf Furniture mount P/2 DA2xi Yes, with optional under-desk mounting kit P/2 DA2xi MT Yes, with included under-desk mount kit or optional through-desk mount kit Pole mount Yes, with optional pole mount kit Enclosure type Metal Enclosure dimensions 1.0" H x 4.3" W x 3.0" D (quarter rack wide)(2.5 cm H x 10.9 cm W x 7.6 cm D)(Depth excludes connectors.) Product weight 0.5 lbs (0.3 kg) Regulatory compliance CE, C-tick, c-UL, UL, FCC Class A, ICES, KCC, VCCI
