Check the listing for details. FM Broadcast Power Amplifier Module 300W (88-108mhz) [NEW]. Condition: New. Listed at 1179.99 USD. ELECTRO BROADCAST RF SHOP PAFM300W - ReV. 4.5 - FM Broadcast Power Amplifier Module 300W Frequency Range: 87.5-108 Mhz NEW, TESTED & UNUSED MODULE RETAIL PRICE: $479 USD NEW REVISION 4.5 !!!!, NOW 300W IN ALL FM BAND!!!! YOU READ SHIPPING, PAYMENT CONDITIONS AND WARRANTY POLICIES!!! OPTION 1 OPTION 2 OPTION 3 OPTION 4 OPTION 5 OPTION 6 OPTION 7 PACK COMPLETE ALL-IN-ONE POWERPACK MODULE FEATURES Model: PAFM300W - ReV. 4.5 Frequency range: 87.5-108Mhz RF power output: 300W typical, 350W max. RF power input: 2W min. , 7W max. Supply: 48VDC / 8A Board dimensions: 10.2 x 5 cm (4" x 2")Transistors included and installed in board. 2pcs MRF151 (By default) MODULE TESTING TESTING EQUIPAMENT: RF INPUT: BIRD 43 CALIBRATED (08/2011) WITH BIRD SLUG 10B. RF OUTPUT: BIRD 43 CALIBRATED (08/2011) WITH BIRD SLUG 250B AND BIRD 50ohm DUMMY LOAD 1000W. POWER SUPPLY: DT 48V/3000W. TEST NEW 4.5 BOARD FREQUENCY (Mhz) 88 92 96 102 108 RF INPUT (W) 2.2 2.5 2.5 4.0 6.5 RF OUTPUT (W) 300 300 300 300 300 SUPPLY (V) 48.1 48.1 48.1 48.1 48.1 I (A) 8.1 8 7.5 7.4 7.1 HEAT (W) 89 85 61 56 42 PDF Datasheet, you can download in this link PACKAGE CONTENTS PAFM300W FM Power Amplifier Module 300W (1pcs) OPTIONS [Option 1] - Lot M2 and M3 screws (+$5) [Option 2] - 2pcs Coax cable RG316 (20cm/8") for RF Input and RF Output (+$10) [Option 3] - Coax cable RG316 (20cm/8") for RF Input and Coax cable RG303 (20cm/8") for RF Output (+$15) [Option 4] - RF Coupler Detector + Low Pass Filter Module board (FLFM600W-9PL) + Coax cable RG316 (10cm/4") + M3 screws (+$80) [Option 5A] - Aluminium Heatsink (150x100x40mm) (+$85)[Option 5B] - Aluminium Heatsink (265x100x40mm) (+$125) [Option 6] - Power Supply 48V/10A (+$130) [Option 7] - RF Power Alarm Control Board (1A) + LCD + Switch Panel (+$150) [PACK COMPLETE A] - Options 1, 2, 4, 5A and 6 (+$279) [PACK COMPLETE B] - Options 1, 2, 4, 5B and 6 (+$319) [ALL-IN-ONE POWERPACK A] - Options 1, 3, 4, 5A, 6 and 7 (+$415) [ALL-IN-ONE POWERPACK B] - Options 1, 3, 4, 5B, 6 and 7 (+$455) NOTE: For this options (4, 5A, 5B, 6, 7, PACK COMPLETE A/B and ALL-IN-ONE POWERPACK A/B), shipping cost is recalculate price. Request price and shipping cost in invoice or you send me a message. PLEASE NOTE ALUMINIUM HEATSINK, FAN AND 48VDC/8.3A POWER SUPPLY REQUIRED FOR MODULE WORKING MODULES MAY BE COMBINED TO GET MORE POWER 500W, 1000W, 2000W, 2500W, 3000W, 5000W, 10000W RF OUTPUT ( RF POWER Combiners and Splitters not supplied) BEST OFFER FOR MODULES QUANTITY (10+ Modules Board) www.electrobroadcastrfshop.com/shop You see my others items for sale, thanks WE HAVE OTHERS PARTS (NEW) MOSFETS, LDMOS, BIPOLAR TRANSISTORS, GAAS FET, RF POWER MODULES MOTOROLA / MACOM / FREESCALE / NXP MRF136 - MRF148 - MRF148A - MRF150 - MRF151 - MRF151G - MRF237 - MRF317 - MRF8372 - UTV8100B - 2N6080 - 2N6081 - 2N6082 - 2N6083 - 2N6084 - 2N6166 - 2N5589 - 2N5590 - 2N5591 - U310 - BFQ68 - MRF6VP2600H - MRF6VP11KH - MRF6VP21KH - MRF6VP41KH - MRFE6VP61K25H - MRF1K50H - MRF1K50N - MRFX1K80H - PRFX1K80H - MRFX1K80N - MRF6V2010N - MRF6V2150N - MRF6V2300N - MRF6V4300N - MRFE6VP100H - MRFE6VP5150N - MRFE6VP5300N - MRFE6VP5600H - MRFE6VP61K25N - MRFE6VP6300H - MRFE6VP6600N - MRFE6VS25L - MRFE6VS25N PHILIPS / NXP / AMPLEON BLF147 - BLF175 - BLF177 - BLF174XR - BLF174XRS - BLF178P - BLF178XR - BLF178XRS - BLF182XR - BLF182XRS - BLF183XR - BLF183XRS - BLF184XR - BLF184XRS - BLF184XRG - BLF188XR - BLF188XRS - BLF188XRG - BLF189XRA - BLF189XRB - BLF278 - BLF574 - BLF574XR - BLF574XRS - BLF578 - BLF578XR - BLF578XRS - BLW50F - BLW98 - BGY22A - BLV25 - BLF861A ST/THOMPSON SD1127 - SD1480 - SD2918 - SD2921 - SD2923 - SD2931 - SD2932 - SD2933 - SD2941 - SD2942 - SD2943 MICROSEMI MS4500 - MS4550 - MS7792 ACRIAN T9-0896 ACR S100-28 CTC-825-28 TRW PT9780 PT9783 MITSUBISHI (RF Power modules) M57792 (806-870 Mhz, 20W OUT, 400mW IN) $49 NEW PART ($100 NORMAL PRICE) M67759 (872-905 Mhz, 6W OUT, 1mW IN) $10 NEW PART ($25 NORMAL PRICE) M67769C (890-915 Mhz, 15W OUT, 1mW IN) $15 NEW PART ($50 NORMAL PRICE) FUJITSU / EUDYNA OTHERS Request your part that you search. REQUEST MORE INFORMATION FOR THIS PARTS OR OTHERS PARTS THAT YOU NEED T/T SHIPPING Shipping to WORLDWIDE!!! The shipping cost to all countries are the same. Shipping cost include handling and shipping. Handling time: 1-3 days Shipping time to USA: 15-90 daysShipping time to Europe: 15-90 daysShipping time to America: 25-90 daysShipping time to Asia: 25-90 daysShipping time to Rest of World: 30-90 days We ship with Postal Service Certified with Tracking number. International Orders: The buyer is responsible for any applicable import duties and local taxes. Please verify with your customs before making your purchase. Please verify your address during checkout. We are not responsible for any wrong or undeliverable addresses. Items will be checked carefully before sent out. If you need insurance shipment, insurance cost is +$3.50 for every $50 or fraction, please, you request it in order of total or invoice total, packages lost I do not care if the package is not insured. PAYMENTS TERMS AND CONDITIONS PAYPAL payment accepted!!!!! For other types of payments request information. THANKS. PAYMENT IS REQUIRED within 3 days of first win!!!, IF NOT, NEGATIVE FEEDBACK AND EBAY REQUIREMENT. If you do not have a PAYPAL account, please go to PAYPAL to register. Bid on the items seriously, this is not free. WARRANTY & RETURN POLICIES The items shipped to you, are NEW, UNUSED, TESTED and WORKING modules. The transistors, mosfets, ldmos or RF semiconductors installed in Module Board have NOT Warranty. For repair, buyer pay shipping cost to seller and return shipping cost for item repaired. The repair of a module, you should consult your seller for an appraisal of cost. Return and refund money for this item, not accepted. We have promotions frequently so please check them out..... Thanks for looking & have a great day!!
