Check the listing for details. Infortrend ESDS S16S-G2240 16-Bay 3U Disk Storage System + Single Controller. Condition: Used. Listed at 2150.00 USD. Infortrend ESDS S16S-G2240 16-Bay 3U Disk Storage System + Single ControllerIn Good Condition, Full Working Order Tested 2 Year WarrantyIncludes1 x Infortrend ESDS S16S-G2240 16-Bay 3U Disk Storage System16 x 3.5" SAS/SATA Hard Drive Bays with 16 Caddies1 x Infortrend ESDS S16S-G2240 Controller Module - 83522GF16D-00102 x Infortrend 530W Power Supplies The ES S16S-G2240 is a 6G SAS-based storage system scalable to accommodate up to 112 6Gb/s SAS drives. Built to last with robust availability and advanced technology, the single-controller S16S-G2240 provides an affordable DAS solution to empower users with the best possible SATA performance. Specification:Host Ports: 6Gb/s SAS x 2Controller: Single controllerCache Memory: Default 1GB, up to 4GBDrive Connectivity:6Gb/s SAS connectivityS.M.A.R.T. supportAutomatic bad-sector reassignmentDedicated bandwidth to each connected driveSupported Drives:2.5" 6Gb/s SAS 10,000 RPM HDD3.5" 6Gb/s SAS 15,000 RPM HDD3.5" 6Gb/s NL-SAS and SATA 7,200 RPM HDDMax. Drive Number:Per system: 16Via expansion enclosures: 112Rack Support:3U, 19-inch rackmountRAID FunctionalityGlobal, designated or enclosure hot-spareRAID levels supported : RAID 0, 1, 3, 5, 6, 10, 30, 50, 60Online expansion by:Adding new drivesCopying and replacing drives with drives of larger capacityRAID migrationConfigurable stripe size and write policy per systemIntelligent drive handling In degraded mode: skips irreparable blocks to continue rebuild In normal operation: data-block verification and repairGreen Design80 PLUS-certified power supplies delivering more than 80% energy efficiencyIntelligent multi-level drive spin-downAvailability and ReliabilityRedundant, hot-swappable hardware modulesCacheSafe technology**Multi-pathing support (EonPath)Device mapper support** Optional BBU and flash backup module need to be purchased to activate CacheSafe technologyNotificationVarious event notification methods including email and SNMP trap.ManagementWeb-based SANWatch management softwareEmbedded RAIDWatchTerminal via RS-232CTelnet and SSHLCD keypad panelSupported OSWindows Server 2003Windows Server 2008, 2008 R2 (including Hyper-V)Red Hat Enterprise LinuxSUSE Linux EnterpriseSun SolarisVMwarePower Supply UnitPower supplies: redundant and hot-swappable 530W x 2 (80 PLUS Bronze)AC voltage: 100VAC @10A to 240VAC @5AFrequency: 47-63 HzEnvironmentalTemperature:Operating: 0°C to 40°CNon-operating: -40°C to 60°CAltitude:Operating: Sea level to 3,048 m (10,000 ft)Non-operating: Sea level to 12,192 m (40,000 ft)Relative humidity: 5% to 95% non-condensing, operating or non-operatingDimensions (W x H x D): 445 x 130 x 514 mm (without chassis ears and protrusions)Weight: 19.66kg/ 43.69lbs (without HDDs) We supply this server with a different specification to suit your requirements; more or less memory, different or additional hard drives, additional network cards etc. Please contact us for a quote. CS 304136 dup .co.uk
