Check the listing for details. PoKeys 57 for USB with Terminals. Condition: New. Listed at 76.93 USD. Product Description PoKeys57U is an easy-to-use USB device that combines a lot of inputs and outputs, and does not require complex programming knowledge. Pokeys57 provides 55 digital I/O (5V tolerant), 7 analog inputs (12-bit). All the I/O are controlled by the provided software which allows either to use the graphical user interface or advanced console type interface. The settings can be stored on the device, so no special software is needed on target system. PoKeys57 can be used as industrial or CNC control or data acquisition board. PoKeys is available with (PoKeys57UT) or without (PoKeys57UN) screw terminals. Features: Compatible with USB 1.1/2.0 HID standard Standard USB keyboard simulation (with triggering support for up/down keys) Standard USB joystick simulation (6 axis, 32 buttons with triggering support) 55 digital inputs with pull-up resistors, freely mappable to virtual USB keyboard’s keys 55 software controlled digital outputs 7 analog inputs (12-bit) with adjustable low-pass filtering support 3-axis 25 kHz or 8-axis 125 kHz Pulse engine Up to 26 encoder pair inputs (3 high-speed encoder inputs, 1 ultra high speed encoder input) Digital counters on specific digital input pins Two 8×8 matrix LED display support Up to 64 256-character long keyboard macro sequences Up to 16×8 matrix keyboard with triggered keys/alternate function support Two 8×8 matrix LED display support Up to 6 high-speed fully configurable PWM outputs support (25MHz PWM timer) HD44780-based character LCD support (up to 4×20 characters) PoExtBus support for adding up to 10 external shift registers = 80 aditiona outputs PoNET devices support (48-key CNC keyboard mapped to matrix keyboard, etc) Support for Connection signal output Support for up to 10 sensors on I2C bus, up to 10 sensors on 1-wire bus and up to 7 analog sensors Communication compatible with PoKeys55 on application layer (data packet structure) Intuitive and user-friendly software Third-party support via communication DLL library and extensive protocol specification document that allows porting to other systems Plugin for Mach3 and Mach4 software, PoKeys as 4-axis external motion controller or general purpose, highly cusomizable Human Machine Interface PoBlocks graphical programming PLC software Support for X-Plane flight simulator See more here: http://forums.x-plane.org/index.php?showtopic=62459 NEW: Support for PoBlocks graphical programming software Requirements: USB connection between host computer and PoKeys57U device Included software requires Windows 2000/XP/Vista/Windows 7/8/10 with .NET framework 3.5 installed (ONLY FOR SYSTEMS WHERE THE DEVICES WILL BE CONFIGURED, TARGET SYSTEM NEEDS NO SOFTWARE INSTALLATION FOR THE DEVICE TO OPERATE AS A STANDARD USB DEVICE). Software PoKeys software package contains – PoKeys configuration software– PoKeys firmware– PoKeys communication library– Manual– PoKeys USB driver (for fast interface)– PoBlocks graphical programming environment– Programming examples for C++, C#, VB.NET, DelphiPoKeys software can be downloaded in the ‘Downloads’ tab.
