Renogy 10A MPPT Solar Charge Controller 36V/48V Battery Rover Boost Regulator

Name: Renogy 10A MPPT Solar Charge Controller 36V/48V Battery Rover Boost Regulator
SKU: 116818422285
Price: 56.73 USD
Availability: InStock

$28.37

$56.73 -50%

Brand Renogy

Condition New

Item ID 116818422285

Protection Level	IP20
Maximum Continuous Charging Current	100 A
Max. Charging Power	450W/36V; 600W/48V
Battery Operating Range	30 ~ 65 VDC
Max Input Current (short-circuit, Isc)	Up to 600W/36V; 800W/48V
Ground Type	Common Negative Lug (M3)
Operating Temperature Range	-31°F ~ 149°F/ -35°C ~ + 65°C
Dimensions	8.8 x 7.6 x 2.9 inch / 224 x 192 x 74.5mm
Battery Types	AGM/Sealed, GEL, FLOODED, LFP, USER*
Operating / Storage Humidity	0-95% RH
Weight	2.65 lbs / 1.2 Kg
Brand	Renogy
Max. PV Input Power	500W/36V; 650W/48V
Type	Solar Charge Controller
Temperature Compensation 2	0mV / ℃ / 2V; no compensation (Lithium)
Solar Input Voltage Range (VOC)	15 ~ 25VDC / 36V; 15 ~ 40VDC / 48V
Storage Temperature Range	-40°F ~ 176°F / -40℃ ~ + 80℃
MPPT Voltage Range	15 ~ 25VDC / 36V; 15 ~ 40VDC / 48V
Rated Charge Current	10A
Temperature Compensation 1	-3mV / ℃ / 2V (Non-Lithium)
Power Consumption	≤ 2W
Application	Home/Garden, Electric Vehicles, Golf Carts, Scooters, Light Strike Vehicle
Max. Terminals Size	16 ~ 2 AWG, M6-12x1
UPC	0810009715757
Current Output	10 A
System Configuration	Off-Grid
Color	Gray
Current Rating	10 A
MPN	RCC10RVRB
Item Length	8.8 in
Current Type	DC
Voltage	48 V
Model	RCC10RVRB
Features	Bluetooth Module, All Daylight Conditions
Charging Mode	MPPT (Maximum Power Point Tracking)
Protection Properties	Short Circuit Protection, Reverse Polarity Protection, Overcurrent Protection, Discharge Protection, Overcharge Protection
Product Line	Renogy Rover

Check the listing for details. Renogy 10A MPPT Solar Charge Controller 36V/48V Battery Rover Boost Regulator. Color: Gray, Condition: New. Listed at 56.73 USD.
