| Brand | Rolls |
|---|---|
| MPN | RM316 |
| Type | Zone Mixer |
| Input Impedance | 10K Ohms balanced Line<br> 600 Ohms balanced Mic<br> 10K Ohms unb |
| Output Impedance | 50 Ohms balanced |
| Max Input Level | Mic: -30 dB<br> Source: +22 dB<br> |
| Phantom Power | (+15 Volts DC) |
| Input Connectors | XLR and RCA |
| Outputs | 3 ea. Phoenix connector |
| Max Gain | 60 dB mic<br> 30 dB line<br> |
| S/N Ratio | > 75 dB |
| THD | < .3% |
| IMD (SMPTE) | < .3% |
| CMRR | 60 dB |
| Frequency Response | 20Hz to 20 kHz +/- 0 dB |
| Power Adapter | 15VDC |
| UPC | 675889003161 |
Check the listing for details. Rolls RM316 Switchable Three Zone Mixer. Condition: New. Listed at 279.00 USD. TheROLLS RM316 Three Zone Mixer combines three microphones or XLR line level signals with three RCA line level source inputs. Each input is switch selected to output to any combination of three zone outputs.
