Check the listing for details. SL-4013 - Digital Sound Level Meter with Separate Microphone. Condition: Brand New. Listed at 310.82 USD. SL-4013 - Digital Sound Level Meter with Separate Microphone Features: - Separate sound probe, easy operation.- Large LCD display, easy to read.- Frequency weighting meets IEC 61672 type 2.- Auto range & manual range.- A & C frequency weighting.- Fast & Slow time weighting. Specifications: Display52 mm x 32 mm LCD (Liquid Crystal Display), 5 digits FunctiondB (A & C frequency weighting), Time weighting(Fast, Slow), Hold, Memory (max. & min.), Peak hold, AC & RS232 output. Measurement Range 30 - 130 dB Resolution 0.1 dB. Accuracy (23 +-5 C) Frequency weighting meet IEC 61672 class 2, calibrating input signal on 94 dB ( 31.5 Hz to 8 KHz), then the accuracy of frequency weighting is specified as following: 31.5 Hz: +- 3 dB, 63 Hz: +- 2.5 dB, 125 Hz: +- 2.0 dB 250 Hz: +- 1.9 dB, 500 Hz: +- 1.9 dB, 1 kHz: +- 1.4 dB2 kHz: +- 2.6 dB, 4 kHz: +- 3.6 dB, 8 kHz: +- 5.6 dBFrequency Weighting Network A weighting: The characteristic is simulated as "Human Ear Listing" response. Typical, if making the environmental sound level measurement, always select to A weighting. C weighting: The characteristic is near the "FLAT" response. Typical, it is suitable for checking the noise of machinery (Q.C. check) & knowing the sound pressure level of the tested equipment. Calibrator B & K (Bruel & kjaer), multifunction acoustic calibrator, model : 4226. Microphone Electric condenser microphone. Size of microphone 1/2 inch standard size Range selector Auto range : 30 to 130 dB. Manual range : 3 range, 30 to 80 dB, 50 to 100 dB, 80 to 130 dB, 50 dB on each step, with over & under range indicating. Time Weighting (Fast & Slow) Fast - t= 200 ms, Slow - t = 500 ms, a)"Fast" range is simulated the human ear response time weighting.b)"Slow" range is easy to get the average values of vibration sound level.c) The "Fast" & "Slow" time weighting range are designed to IEC 61672 class 2 requirement Output Signal a) AC output - AC 0.5 Vrms corresponding to each range step. Output impedance - 600 ohm. b) RS232 output. Output terminal Terminal 1 : RS232 computer interface terminal.Terminal 2 : AC output terminal.* Terminal socket size : 3.5 mm dia. phone socket Calibration VR Build in external calibration VR, easy to calibrate on 94 dB level by screw driver Operating Temp. 0 to 50 C (32 to 122 F) Operating Humidity Less than 80% RH. Power Supply 006P DC 9V battery ( Alkaline or heavy duty type ). Power Consumption Approx. DC 6mA. Dimension Main instrument: 205 x 68 x 29 mm ( 8.07x2.7x1.1 inch ).Sound probe: 170.5 x 24.5 x 19 mm ( 6.7x1.0x0.7 inch ) Weight 405 g/0.89 LB ( including probe ). Standard Accessories Instruction manual ...................................1 PC.Separate sound probe............................... 1 PC.Probe holder............................................. 1 PC SL-4013 - Digital Sound Level Meter with Separate Microphone Features: - Separate sound probe, easy operation.- Large LCD display, easy to read.- Frequency weighting meets IEC 61672 type 2.- Auto range & manual range.- A & C frequency weighting.- Fast & Slow time weighting. Specifications: Display52 mm x 32 mm LCD (Liquid Crystal Display), 5 digits Function dB (A & C frequency weighting), Time weighting(Fast, Slow), Hold, Memory (max. & min.), Peak hold, AC & RS232 output. Measurement Range 30 - 130 dB Resolution 0.1 dB. Accuracy (23 +-5 C) Frequency weighting meet IEC 61672 class 2, calibrating input signal on 94 dB ( 31.5 Hz to 8 KHz), then the accuracy of frequency weighting is specified as following: 31.5 Hz: +- 3 dB, 63 Hz: +- 2.5 dB, 125 Hz: +- 2.0 dB 250 Hz: +- 1.9 dB, 500 Hz: +- 1.9 dB, 1 kHz: +- 1.4 dB2 kHz: +- 2.6 dB, 4 kHz: +- 3.6 dB, 8 kHz: +- 5.6 dB Frequency Weighting Network A weighting: The characteristic is simulated as "Human Ear Listing" response. Typical, if making the environmental sound level measurement, always select to A weighting. C weighting: The characteristic is near the "FLAT" response. Typical, it is suitable for checking the noise of machinery (Q.C. check) & knowing the sound pressure level of the tested equipment. Calibrator B & K (Bruel & kjaer), multifunction acoustic calibrator, model : 4226. Microphone Electric condenser microphone. Size of microphone 1/2 inch standard size Range selector Auto range : 30 to 130 dB. Manual range : 3 range, 30 to 80 dB, 50 to 100 dB, 80 to 130 dB, 50 dB on each step, with over & under range indicating. Time Weighting (Fast & Slow) Fast - t= 200 ms, Slow - t = 500 ms, a)"Fast" range is simulated the human ear response time weighting.b)"Slow" range is easy to get the average values of vibration sound level.c) The "Fast" & "Slow" time weighting range are designed to IEC 61672 class 2 requirement Output Signal a) AC output - AC 0.5 Vrms corresponding to each range step. Output impedance - 600 ohm. b) RS232 output. Output terminal Terminal 1 : RS232 computer interface terminal.Terminal 2 : AC output terminal.* Terminal socket size : 3.5 mm dia. phone socket Calibration VR Build in external calibration VR, easy to calibrate on 94 dB level by screw driver Operating Temp. 0 to 50 C (32 to 122 F) Operating Humidity Less than 80% RH. Power Supply 006P DC 9V battery ( Alkaline or heavy duty type ). Power Consumption Approx. DC 6mA. Dimension Main instrument: 205 x 68 x 29 mm ( 8.07x2.7x1.1 inch ).Sound probe: 170.5 x 24.5 x 19 mm ( 6.7x1.0x0.7 inch ) Weight 405 g/0.89 LB ( including probe ). Standard Accessories Instruction manual ...................................1 PC.Separate sound probe............................... 1 PC.Probe holder............................................. 1 PC &times Buy now and save! Shipping info Click the Shipping & Payments tab above the listing description for more info FREE Shipping See more... Star Track Express - $0.00 Standard International Flat Rate Postage - $45.00 Click the Shipping & Payments tab above the listing description for more info! Additional delivery notes PICK UP OPTION Sorry, our items are NOT available for pick-up. PAYMENT Immediate payment is required upon selecting "Buy It Now" or upon checking out through the cart. We accept payment via All Major Credit Cards (Visa, Mastercard, AMEX, Discover), Google Pay, PayPal, & Apple Pay (on mobile & eBay App). Thank you for shopping with us on eBay! Additional Information No additional information at this time Ask seller a question You might also like BenchTop Water Quality Meter - IC860033 Battery Coolant Refractometer - IC300014 4 Channel Thermocouple Data Logger USB Humidity Data Logger with Dew Point & Temp. - EL-USB-2 Contact To contact our Customer Service Team, simply click the button here and our Customer Service team will be happy to assist. Ask seller a question © Instrument Choice Shipping & Payments Shipping is FREE for this item Payment Accepted Payment Methods Immediate payment is required upon selecting "Buy It Now" or upon checking out through the cart. We accept payment via All Major Credit Cards (Visa, Mastercard, AMEX, Discover), Google Pay, PayPal, & Apple Pay (on mobile & eBay App). Thank you for shopping with us on eBay! Returns Returns are accepted Items must be returned within 30 days of the auction ending Seller will pay for return shipping. eBay integration by
