| All returns accepted | ReturnsNotAccepted |
|---|---|
| Model | STA-35H |
| MPN | Does Not Apply |
| Country/Region of Manufacture | China |
Check the listing for details. STA-35H GNSS RTK Antenna for agricultural, mapping (replace Trimble AG25). Condition: New. Listed at 300.00 USD. I am selling a new STA-35H GNSS Antenna Magnet RTK GPS / Galileo / Glonass / BDS / L-Band / SBAS for Agricultural, Geodesy and Mapping (Replace Trimble AG25). Antenna Patch Architecture Dual Four-point-feed, Dual Stacked Patch Supported positioning signal bands GPS:L1/L2/L5; BDS:B1/B2/B3; GLONASS:G1/G2/G3; Galileo:El/E5a/E5b/E6 L-Band SBAS EGNOS Peak Gain ≥5.0dBi@Fc Polarization RHCP Axial Ratio@zenith ≤1.5dB Azimuth Coverage 360° Impedance 50 ohm Phase-center accuracy ≤2.0mm Phase-center repeatability ≤1.0mm LNA Frequency Range 1164MHz~1300MHz 1525MHz~1621MHz LNA Gain 40±2.0dB (Typ. @25°C) Group Delay variation ≤5ns Noise Figure ≤2.0 dB@25°C , Typ.(Pre-filtered) Output VSWR ≤1.8:1 typ. 2.0:1max Operation Voltage 3.0~16.0V DC Operation Current ≈45mA Mechanicals & Environmental Dimension Φ152mm*67.5mm Connector TNC ( Female) Radome PC+PBT Weight ≈430g Attachment Method 5/8-11 Operating Temp -40℃~+85℃ Storage Temp -45℃~+85℃ Humidity 95% No-condensing Waterproof IP67 It comes exactly as pictured nothing more or less. What you see is what you get. *About the 'Custom Duty* : My price don't include any 'Custom Duty'. I can declare the value as your requirement. But I won't afford any 'Custom Duty'. Thanks!
