Check the listing for details. Supermicro A2SDi-TP8F Mini-ITX Motherboard. Condition: New. Listed at 1095.69 USD. Key Features Intel® Atom® Processor C3858., Single Socket FCBGA1310 supported, CPU TDP support 25WSystem on ChipUp to 64GB Unbuffered ECC/non-ECC SO-DIMM, DDR4-2400MHz, in 4 DIMM slots1 PCI-E 3.0 x41 miniPCI-E with mSATA supports (half card only) M.2 Interface: PCI-E 3.0 x4 and SATA M.2 Form Factor: 2242, 2280 M.2 Key: M-Key1 VGA portSoC controller for 4 SATA3 (6 Gbps) ports;Quad LAN with Intel® C3000 SoC 2 10GBaseT, 2 10Gb SFP+ Quad LAN with Intel® Ethernet Controller I350-AM4 1GbE Links & Resources Tested Memory List Tested HDD / SSD List Tested AOC List Motherboard Manual Quick Reference Guide Update Your BIOS BMC/IPMI Firmware Download the Latest Drivers and Utilities Download Driver CDOS Compatibility Product SKUs MBD-A2SDi-TP8F A2SDi-TP8F Physical Stats Form Factor Mini-ITX Dimensions 6.7" x 6.7" (17.02cm x 17.02cm) Processor/Cache CPU Intel® Atom® Processor C3858.Single Socket FCBGA1310 supported, CPU TDP support 25W Cores / Cache 12 cores, 12 threads / 12MB cache System Memory Memory Capacity Up to 64GB Unbuffered ECC/non-ECC SO-DIMM, DDR4-2400MHz, in 4 DIMM slots Memory Type 2400/2133/1866/1600MHz DIMM Sizes 4GB, 8GB, 16GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset System on Chip SATA SoC controller for 4 SATA3 (6 Gbps) ports; IPMI ASPEED AST2400 BMC Network Controllers Quad LAN with Intel® C3000 SoC 2 10GBaseT, 2 10Gb SFP+ Quad LAN with Intel® Ethernet Controller I350-AM4 1GbE Graphics Aspeed AST2400 BMC Input / Output SATA 4 SATA3 (6Gbps) port LAN 4 RJ45 Gigabit Ethernet LAN ports2 10G SFP+ LAN ports2 RJ45 10GBase-T ports USB 4 USB 2.0 ports (4 headers),2 USB 3.0 ports (2 rear) Video Output 1 VGA port Serial Port / Header 1 COM Port (1 header) TPM TPM Header Expansion Slots PCI-E 1 PCI-E 3.0 x41 miniPCI-E with mSATA supports (half card only) M.2 M.2 Interface: PCI-E 3.0 x4 and SATAForm Factor: M-Key 2242, 2280 System BIOS BIOS Type AMI UEFI BIOS Features UEFI 2.4SMBIOS 2.7.1 Management Software IPMI2.0, KVM with dedicated LAN, NMI, SUM, SuperDoctor® 5, Watchdog Power Configurations ATX Power connector+12V DC Power InputCPU thermal trip support for processor protectionPower-on mode for AC power recovery PC Health Monitoring Voltage +1.8V, +12V, +5V, 1.05 (PCH), 1.2V (VDIMM), 4 -fan status, 4 fans with tachometer monitoring, Chassis intrusion header, Monitors CPU voltages, Supports system management utility, System level control, System temperature, VBAT, VCGI FAN 4x 4-pin fan headers (up to 4 fans), 4 fans with tachometer monitoring, Dual Cooling Zone, Fan speed control, Overheat LED indication, Pulse Width Modulated (PWM) fan connectors, Status monitoring for speed control, Support 3-pin fans (w/o speed control), System level control, Thermal control tachometer fan connectors Temperature CPU thermal trip support LED UID/Remote UID Other Features 12V DC or ATX Power Source, 4-pin 12v DC power connector, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Innovation Engine, RoHS, SDDC, System level control, UID, WOL Operating Environment Operating Temperature Range 0°C ~ 60°C (32°F ~ 140°F) Non-Operating Temperature Range -40°C - 85°C (-40°F - 185°F) Operating Relative Humidity Range 10% ~ 85% (non-condensing) Non-Operating Relative Humidity Range 10% ~ 95% (non-condensing) Parts List (Bulk Package) Name Part Number Qty Description Motherboard MBD-A2SDi-TP8F 1 A2SDi-TP8F Motherboard SATA Cables CBL-0044L257.5CM SATA FLAT S-S PBF I/O ShieldMCP-260-00098-0N1Standard I/O Shield for A2SDi-TP8F
