Touch Switch T1 Stepless Dimming Switch DC 6V to 24V Blue LED Suitable for 19...

Name: Touch Switch T1 Stepless Dimming Switch DC 6V to 24V Blue LED Suitable for 19...
SKU: 318059763340
Price: 23.99 USD
Availability: InStock

$16.79

$23.99 -30%

Brand Unbranded

Condition New

Item ID 318059763340

Protection Level	Ik10
Unit Count	1 Count
Item Dimensions L X W X H	7.09 X 0.87 X 0.87 Inches
Head Diameter	7/8" ( 22mm )
Controller Type	Ring
Wattage	168 Watts
Material Type	Stainless Steel
Contact Type	Normally Open
Mounting Hole Size	3/4" ( 19mm )
Current Type	DC
Operating Voltage	24 Volts
Connectivity Protocol	X-10
Depth Inc Contacts	1.1" ( 28mm )
Connector Type	Wire
Contact Material	Copper, Brass
Led Color	Blue (always On)
Enclosure Material	Stainless Steel
Specification Met	Ik10,
Led Voltage	Dc 6v-24v
Operating Temperature	-20℃ ～ +55℃
Color	Blue
Actuator Type	Push Button
Control Method	Touch
Output Current	7a Max
Current Rating	7 Amps
Switch Type	Touch Switch
Material	Stainless Steel
Input Voltage	Dc 6v-24v
Mounting Type	Panel Mount
Terminal	Pins
Operation Mode	Manual
Brand	Unbranded
Number Of Positions	2
Bulb Compatibility	LED
Circuit Type	1-way
Item Dimensions	7.09 X 0.87 X 0.87 Inches
Upper Temperature Rating	55 Degrees Celsius
Item Weight	0.01 Ounces
Country of Origin	China

Check the listing for details. Touch Switch T1 Stepless Dimming Switch DC 6V to 24V Blue LED Suitable for 19.... Color: Blue, Condition: New, Made in China. Listed at 23.99 USD. Touch Switch T1 Stepless Dimming Switch DC 6V to 24V Blue LED Suitable for 19mm 3/4" Mounting Hole. About Stepless Dimming type The brightness increases when touching and holding, and stays at the level when stop holding.
