Check the listing for details. USB 24MHz 8CH 24MHz Logic Analyzer Device Set USB Cable For ARM FPGA M100 Set. Condition: New. Listed at 10.77 USD. This item is an logic analyzer designed to be compatible with Logic Analyzer software, The logic for each channel sampling rate of 24M/s. General applications around 10M, enough to cope with a variety ofoccasions; 8-channel.Sampling rate up to: 24 MHz , can be 24MHz. 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz;Input voltage range: -0.5V to 5.25V; Input Low Voltage: -0.5V to 0.8V; Input High Voltage: 2.0V to 5.25V, Input Impedance: 1Mohm || 10pF (typical, approximate); Crystal: +/-20ppm, 24MHz.A total of 8 digital channels, the voltage range is 0V and 5.5V, of which 1.5V is the voltage threshold, below 1.5V is considered low, above 1.5V is considered high, Works with 5V, 3.3V, 2.5V, 2.0V systems. May work with 1.8V but not recommended.Error/Accuracy: pulse-width measurement: +/- 42ns (at 24MHz).UART, SPI, IIC and other communication debugging, 24M sampling rate, can automatically analyze UART, IIC, SPI and many other standard protocols.Suitable for single chip development,ARM system development,FPGA development.Product descriptionDigital Channels: 8Voltage range:Input voltage range: -0.5V to 5.25VInput Low Voltage: -0.5V to 0.8VInput High Voltage: 2.0V to 5.25VWorks with 5V, 3.3V, 2.5V, 2.0V systems. May work with 1.8V but not recommended.Input Impedance: 1Mohm || 10pF (typical, approximate)Crystal: +/-20ppm, 24MHzError/Accuracy: pulse-width measurement: +/- 42ns (at 24MHz).Material:Metal,Plastic。Large quantity sample collection, strong and powerful.Equipped with overpressure protection, for safety working.Suitable for single chip development,ARM system development,FPGA development.Quantity: 1PC
