Check the listing for details. Voltage Measurement DAQ HAT 6069-410-000. Condition: New. Listed at 109.00 USD. Voltage Measurement DAQ HAT MCC-118. Voltage Measurement DAQ HAT for Raspberry Pi. 8 SE Analog Input, 12-bit, 100KS/s. Range +-10VDC. Power: 3.3 V provided by Raspberry pi. Up to eight MCC 118 devices can be stacked. Raspberry Pi is not included. The MCC 118 is a voltage HAT (Hardware Attached on Top) board designed for use with Raspberry Pi, the most popular single-board computer on the market today. A HAT is an add-on board with a 40W GPIO (general purpose input/output) connector that conforms to the Raspberry Pi HAT specification. The MCC 118 HAT provides eight single-ended (SE) analog inputs for voltage measurements. Up to eight MCC HATs can be stacked onto one Raspberry Pi. Features: Eight 12-bit voltage inputs. 100 kS/s max sample rate (320 kS/s aggregate for stacked boards). ±10 V input range. Onboard sample buffers allow high-speed acquisition. External scan clock I/O. External digital trigger input. Screw terminal connections. Stack up to eight MCC HATsonto a single Raspberry Pi. Technical DataAnalog InputA/D convertertype Successive approximationADC resolution12 bitsNumber of channels8 single-endedInput voltage range±10 VAbsolute maximum input voltage CHx relative to GND±25 V max (power on or power off)Input impedance1 MO (power on or power off)Input bias current10 V input –12 µA0 V input2 µA–10 V input12 µAMonotonicityGuaranteedInput bandwidth, small signal (–3 dB)150 kHzMaximum working voltage Input range relative to AGND±10.1 V maxCrosstalk (adjacent channels, DC to 10 kHz)–75 dBInput couplingDCRecommended warm-up time1 minute minSample rate, hardware paced Internal scan clock0.004 S/s to100 kS/s, software-selectableExternal scan clock100 kS/s maxSampling mode1 A/D conversion for each configured channel per clockConversion time, per channel8 µsScan clock source Internal scan clockExternal scan clock input on terminal CLKChannel queue Up to eight unique, ascending channelsThroughput, Raspberry Pi® 2 / 3Single board100 kS/s maxMultiple boardsUp to 320 kS/s aggregate*Throughput, Raspberry Pi A+ / B+ Single boardUp to 100 kS/s*Multiple boardsUp to 100 kS/s aggregate*Accuracy Analog Input DC Voltage Measurement Accuracy AccuracyRange±10 VGain error (% of reading)0.098 maxOffset error11 mV maxAbsolute accuracy at full scale20.8 mVGain temperature coefficient(% reading/°C)0.016Offset temperature coefficient (mV/°C)0.87Noise PerformanceRange±10 VCounts5LSBrms0.76 External Digital TriggerTrigger sourceTRIG inputTrigger modeSoftware-selectable for rising or falling edge, or high or low levelTrigger latency Internal scan clock1 µs maxExternal scan clock1 µs + 1 scan clock cycle maxTrigger pulse width125 ns minInput typeSchmitt trigger, weak pull-down to ground (approximately 10 K)Input high voltage threshold2.64 V minInput low voltage threshold0.66 V maxInput voltage limits5.5 V absolute max, –0.5 V absolute min, 0 V recommended minExternal Scan Clock Input/OutputTerminal nameCLKTerminal typesBidirectional, defaults to input when not sampling analog channelsDirection (software-selectable) OutputOutputs internal scan clock, active on rising edgeInputReceives scan clock from external source, active on rising edgeInput clock rate100 kHz maxClock pulse width400 ns minInput typeSchmitt trigger, weak pull-down to ground (approximately 10 K), protected with a 150 kO series resistorInput high voltage threshold2.64 V minInput low voltage threshold0.66 V maxInput voltage limits5.5 V absolute max, –0.5 V absolute min, 0 V recommended minOutput high voltage3.0 V min (IOH = –50 µA), 2.65 V min (IOH = –3 mA)Output low voltage0.1 V max (IOL = 50 µA), 0.8 V max (IOL = 3 mA)Output current±3 mA maxMemoryData FIFO7 K (7,168) analog input samplesNon-volatile memory4 KB (ID and calibration storage, no user-modifiable memory)PowerSupply current3.3 V supplyTypical35 mAMaximum55 mAInterfaceRaspberry Pi GPIO pins usedGPIO 8, GPIO 9, GPIO 10, GPIO 11 (SPI interface) ID_SD, ID_SC (ID EEPROM) GPIO 12, GPIO 13, GPIO 26, (Board address) Data interface typeSPI slave device, CE0 chip selectSPI mode1SPI clock rate10 MHz, maxEnvironmentOperating temperature0 °C to 55 °CStorage temperature–40 °C to 85 °C maxRelative humidity0% to 90% non-condensingMechanicalDimensions (L × W × H)65 × 56.5 × 12 mm (2.56 × 2.22 × 0.47 in.) max
