Check the listing for details. Wichard Diamond Padeye Square L98 #6656. Condition: New. Listed at 46.70 USD. Download Literature Wichard Marine 6656 Sailing Accessories Diamond Pad Eye - Square - 98mm Length (3-55/64") - M8 Screw Features: Mechanical resistance versus corrosion resistance ratio Optimized dimensions For M8 screw Applications: Mast foot blocks Reefing blocks Various fastenings Specifications: Materials: Duplex stainless steel grade Working Load: (lb) 9479.8 / (kg) 4300 Breaking Load: (lb) 25573.6 / (kg) 11600 Weight: (lb) 0.562 / (g) 255 W.L 1 (90 degrees): (lb) 9479.8 / (kg) 4300 W.L 2 (45 degrees): (lb) 9479.8 / (kg) 4300 W.L 3 (0 degrees): (lb) 9038.9 / (kg) 4100 B.L 1 (90 degrees): (lb) 25573.6 / (kg) 11600 B.L 2 (45 degrees): (lb) 25573.6 / (kg) 11600 B.L 3 (0 degrees): (lb) 24250.8 / (kg) 11000 Dimensions: A: (inch) 3 55/64" / (mm) 98 B: (inch) 2 7/8" / (mm) 73 C: (inch) 2 21/64" / (mm) 59 D: (inch) 1 3/8" / (mm) 35 E: (inch) 49/64" / (mm) 19.5 F: (inch) 1 1/16" / (mm) 27 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Normalized SKU: 6656Wichard Marine 6656 Literature Download Quick Reference Guide
